Acronym ...
Name hyperbolic "NMKLP ike + 4NKLP x3o5x5*a + 6NMLP topepat + 4NMKP hipat + 6NMKL peat" honeycomb
Circumradius sqrt[-(67 sqrt(5)-145)/710] = 0.082364 i
Vertex figure
 ©
Edge figures

This hypercompact hyperbolic tesselation uses the hyperbolic tilings x3o5x5*a, topepat, hipat, and peat in the sense of infinite bollohedra as some types of its cells.


Incidence matrix

(N,M,K,L,P → ∞)

 NMKLP |      60     120 |      60     120      60      60      60 |    12    60    60    20    30
-------+-----------------+-----------------------------------------+------------------------------
     2 | 30NMKLP       * |       2       2       0       0       0 |     1     2     1     0     0
     2 |       * 60NMKLP |       0       1       1       1       1 |     0     1     1     1     1
-------+-----------------+-----------------------------------------+------------------------------
     3 |       3       0 | 20NMKLP       *       *       *       * |     1     1     0     0     0
    10 |       5       5 |       * 12NMKLP       *       *       * |     0     1     1     0     0
     5 |       0       5 |       *       * 12NMKLP       *       * |     0     0     1     1     0
     5 |       0       5 |       *       *       * 12NMKLP       * |     0     1     0     0     1
     5 |       0       5 |       *       *       *       * 12NMKLP |     0     0     0     1     1
-------+-----------------+-----------------------------------------+------------------------------
    12 |      30       0 |      20       0       0       0       0 | NMKLP     *     *     *     *  ike (magenta)
   15M |     15M     15M |      5M      3M       0      3M       0 |     * 4NKLP     *     *     *  x3o5x5*a (blue)
   10K |      5K     10K |       0      2K      2K       0       0 |     *     * 6NMLP     *     *  topepat, x5x5o (green)
    5L |       0     15L |       0       0      3L       0      3L |     *     *     * 4NMKP     *  hipat, x5o6o (red)
    5P |       0     10P |       0       0       0      2P      2P |     *     *     *     * 6NMKL  peat, o4o5x (yellow)
