This paracompact hyperbolic tesselation uses the euclidean tiling squat in the sense of an infinite horohedron as one type of its cells.

Incidence matrix

(N,M → ∞)

5NM |   24   24    48 |   24   48   48   12   48   24   24 |   6   24   48   24  24   8
----+-----------------+------------------------------------+---------------------------
  2 | 60NM    *     * |    2    2    2    0    0    0    0 |   1    2    2    1   0   0
  2 |    * 60NM     * |    0    2    0    1    2    0    0 |   0    1    2    0   2   0
  2 |    *    * 120NM |    0    0    1    0    1    1    1 |   0    0    1    1   1   1
----+-----------------+------------------------------------+---------------------------
  4 |    4    0     0 | 30NM    *    *    *    *    *    * |   1    1    0    0   0   0
  4 |    2    2     0 |    * 60NM    *    *    *    *    * |   0    1    0    1   0   0
  4 |    2    0     2 |    *    * 60NM    *    *    *    * |   0    0    2    0   0   0
  3 |    0    3     0 |    *    *    * 20NM    *    *    * |   0    0    0    0   2   0
 10 |    0    5     5 |    *    *    *    * 24NM    *    * |   0    0    1    0   1   0  {10/3}
  3 |    0    0     3 |    *    *    *    *    * 40NM    * |   0    0    0    1   0   1
  5 |    0    0     5 |    *    *    *    *    *    * 24NM |   0    0    0    0   1   1  {5/2}
----+-----------------+------------------------------------+---------------------------
  M |   2M    0     0 |    M    0    0    0    0    0    0 | 30N    *    *    *   *   *  squat
  8 |    8    4     0 |    2    4    0    0    0    0    0 |   * 15NM    *    *   *   *  cube
 20 |   10   10    10 |    0    0   10    0    2    0    0 |   *    * 12NM    *   *   *  stiddip
  6 |    3    0     6 |    0    3    0    0    0    2    0 |   *    *    * 20NM   *   *  trip
 60 |    0   60    60 |    0    0    0   20   12    0   12 |   *    *    *    * 2NM   *  gaddid
 20 |    0    0    60 |    0    0    0    0    0   20   12 |   *    *    *    *   * 2NM  sidtid
