Acronym tistadip
Name triangle - pentagram duoprism,
pentagram - stip wedge


 ©
Circumradius sqrt[(25-3 sqrt(5))/30] = 0.780850
Dihedral angles
Face vector 15, 30, 23, 8
Confer
general duoprisms:
n/d,m/b-dip
general polytopal classes:
segmentochora   bistratic lace towers
External
links
hedrondude   wikipedia   polytopewiki

As abstract polytope tistadip is isomorphic to trapedip, thereby replacing pentagrams by pentagons, resp. stip by pip.


Incidence matrix according to Dynkin symbol

x3o x5/2o

. . .   . | 15 |  2  2 | 1  4 1 | 2 2
----------+----+-------+--------+----
x . .   . |  2 | 15  * | 1  2 0 | 2 1
. . x   . |  2 |  * 15 | 0  2 1 | 1 2
----------+----+-------+--------+----
x3o .   . |  3 |  3  0 | 5  * * | 2 0
x . x   . |  4 |  2  2 | * 15 * | 1 1
. . x5/2o |  5 |  0  5 | *  * 3 | 0 2
----------+----+-------+--------+----
x3o x   .   6 |  6  3 | 2  3 0 | 5 *
x . x5/2o  10 |  5 10 | 0  5 2 | * 3

x3o x5/3o

. . .   . | 15 |  2  2 | 1  4 1 | 2 2
----------+----+-------+--------+----
x . .   . |  2 | 15  * | 1  2 0 | 2 1
. . x   . |  2 |  * 15 | 0  2 1 | 1 2
----------+----+-------+--------+----
x3o .   . |  3 |  3  0 | 5  * * | 2 0
x . x   . |  4 |  2  2 | * 15 * | 1 1
. . x5/3o |  5 |  0  5 | *  * 3 | 0 2
----------+----+-------+--------+----
x3o x   .   6 |  6  3 | 2  3 0 | 5 *
x . x5/3o  10 |  5 10 | 0  5 2 | * 3

x3/2o x5/2o

.   . .   . | 15 |  2  2 | 1  4 1 | 2 2
------------+----+-------+--------+----
x   . .   . |  2 | 15  * | 1  2 0 | 2 1
.   . x   . |  2 |  * 15 | 0  2 1 | 1 2
------------+----+-------+--------+----
x3/2o .   . |  3 |  3  0 | 5  * * | 2 0
x   . x   . |  4 |  2  2 | * 15 * | 1 1
.   . x5/2o |  5 |  0  5 | *  * 3 | 0 2
------------+----+-------+--------+----
x3/2o x   .   6 |  6  3 | 2  3 0 | 5 *
x   . x5/2o  10 |  5 10 | 0  5 2 | * 3

x3/2o x5/3o

.   . .   . | 15 |  2  2 | 1  4 1 | 2 2
------------+----+-------+--------+----
x   . .   . |  2 | 15  * | 1  2 0 | 2 1
.   . x   . |  2 |  * 15 | 0  2 1 | 1 2
------------+----+-------+--------+----
x3/2o .   . |  3 |  3  0 | 5  * * | 2 0
x   . x   . |  4 |  2  2 | * 15 * | 1 1
.   . x5/3o |  5 |  0  5 | *  * 3 | 0 2
------------+----+-------+--------+----
x3/2o x   .   6 |  6  3 | 2  3 0 | 5 *
x   . x5/3o  10 |  5 10 | 0  5 2 | * 3

ox xx5/2oo&#x    → height = sqrt(3)/2 = 0.866025
({5/2} || stip)

o. o.5/2o.    | 5  * | 2  2 0  0 | 1 1  4 0 0 | 2 2 0
.o .o5/2.o    | * 10 | 0  1 1  2 | 0 1  2 2 1 | 2 1 1
--------------+------+-----------+------------+------
.. x.   ..    | 2  0 | 5  * *  * | 1 0  2 0 0 | 1 2 0
oo oo5/2oo&#x | 1  1 | * 10 *  * | 0 1  2 0 0 | 2 1 0
.x ..   ..    | 0  2 | *  * 5  * | 0 1  0 2 0 | 2 0 1
.. .x   ..    | 0  2 | *  * * 10 | 0 0  1 1 1 | 1 1 1
--------------+------+-----------+------------+------
.. x.5/2o.    | 5  0 | 5  0 0  0 | 1 *  * * * | 0 2 0
ox ..   ..&#x | 1  2 | 0  2 1  0 | * 5  * * * | 2 0 0
.. xx   ..&#x | 2  2 | 1  2 0  1 | * * 10 * * | 1 1 0
.x .x   ..    | 0  4 | 0  0 2  2 | * *  * 5 * | 1 0 1
.. .x5/2.o    | 0  5 | 0  0 0  5 | * *  * * 2 | 0 1 1
--------------+------+-----------+------------+------
ox xx   ..&#x  2  4 | 1  4 2  2 | 0 2  2 1 0 | 5 * *
.. xx5/2oo&#x  5  5 | 5  5 0  5 | 1 0  5 0 1 | * 2 *
.x .x5/2.o     0 10 | 0  0 5 10 | 0 0  0 5 2 | * * 1
